Dark-field X-ray technology improves diagnosis of pulmonary ailments
New X-ray technology first used with patients
There are millions of cases in which serious respiratory system illnesses place limitations on quality of life. Every year more than four million people die of serious respiratory ailments worldwide. Partially destroyed alveoli and an over-inflation of the lungs (emphysema) are typical of the life-threatening ailment Chronic Obstructive Pulmonary Disease (COPD).
However, the fine distinctions between healthy and diseased tissue are barely visible on conventional chest X-rays. Detailed diagnostic information is only available using three-dimensional computed tomography approaches, in which the computer assembles many individual images. Until now there has been no fast and cost-effective option for early detection and follow-up examinations with a low radiation exposure as used in plain chest X-rays.
A procedure developed at the Technical University of Munich could now fill this gap: dark-field chest X-rays. In the current issue of "Lancet Digital Health" a research team led by Franz Pfeiffer, Professor for Biomedical Physics and Director of the Munich Institute of Biomedical Engineering at TUM, is now presenting the results of an initial clinical patient study, which used the new X-ray technology for the diagnosis of the lung disease COPD.
The key: The wave character of X-rays
Conventional X-ray imaging is based on the attenuation of X-rays on their way through the tissue. Dark-field technology on the other hand uses the wave nature of X-ray light, which is discarded in conventional X-ray imaging.
The new method thus uses the physical phenomenon of scattering in a manner similar to the long-known principle of dark-field microscopy with visible light. This makes it possible to visualize the structure of objects that are for the most part transparent. These structures appear in the microscope as bright images on a dark background, which has given the method its name.
"The X-ray dark-field signal is particularly strong for interfaces between air and tissue," Pfeiffer points out. "This makes it possible for a dark-field X-ray image of the lung to clearly distinguish between intact alveoli, i.e. those filled with air, and regions in which less intact alveoli exist."
Lower radiation dose
In addition, an examination using dark-field chest X-ray technology involves a significantly lower radiation dose than presently used computed tomography. This is because dark-field chest X-rays require only one exposure per patient, as compared to the large number of individual images taken from different directions which are necessary in computed tomography.
"We expect the radiation exposure to be reduced by a factor of fifty," says Franz Pfeiffer. Furthermore, the first clinical results have confirmed that the dark-field X-rays provide additional image information on the underlying microstructure of the lung.
"Given the close connection between the alveolar structure and the functional condition of the lung, this ability is of great significance for pulmonary medicine," explains Dr. Alexander Fingerle, senior physician at TUM’s university hospital Klinikum rechts der Isar's Department of Diagnostic and Interventional Radiology. "In the future dark-field X-rays could help improve early detection of COPD and other respiratory ailments."
Better X-ray equipment for early detection in the future
Franz Pfeiffer hopes these initial clinical results with patients will accelerate the execution of further clinical studies and the development of marketable devices that use the dark-field method.
"Dark-field chest X-rays are currently giving us a chance to significantly improve the early detection of lung diseases and at the same time to implement it on a wider basis than before," Pfeiffer points out.
Since dark-field imaging is not limited to COPD, further translational studies with other pulmonary pathologies such as pulmonary fibrosis, pneumothorax, lung cancer and pneumonia, including COVID-19, are of great interest.
Konstantin Willer, Alexander Fingerle, Wolfgang Noichl, Fabio De Marco, Manuela Frank, Theresa Urban, Rafael Schick, Alex Gustschin, Bernhard Gleich, Julia Herzen, Thomas Koehler, Andre Yaroshenko, Thomas Pralow, Gregor Zimmermann, Bernhard Renger, Andreas Sauter, Daniela Pfeiffer, Marcus Makowski, Ernst Rummeny, Philippe Grenier, Franz Pfeiffer
X-ray dark-field chest imaging for detection and quantification of emphysema in patients with chronic obstructive pulmonary disease: a diagnostic accuracy study
Lancet Digital Health, Volume 3, ISSUE 11, e733-e744, November 01, 2021 – DOI: 10.1016/S2589-7500(21)00146-1
The research was supported by the European Research Council as part of an Advanced Grant and by Philips Medical Systems DMC GmbH. Co-author Thomas Köhler (Philips) was Rudolf Diesel Industry Fellow at the TUM Institute for Advanced Study (TUM IAS), which itself is funded in part by the Excellence Initiative of the German federal and state governments and by the EU's Marie Curie COFUND program. Some of the research was conducted in collaboration with the Karlsruhe Nano Micro Facility (KNMF), a Helmholtz research infrastructure at the Karlsruhe Institute of Technology (KIT).
